Portable Breakout System - 21,500 ft-lb

Application

• Torquing up and breaking out direct connected horizontal directional drill tooling
• Frequently used on the exit side to break out drill head and connect reamer
• Also known as “wrenches” or “tongs”

Compatibility

• Grip inserts facilitate a grip range of 3.25” – 5.75” (8.3 cm – 14.6 cm)
• An additional die set, facilitating 2.5” – 3.75” (6.3 cm – 9.5 cm) is available for order separately (PN 296522914)
• Intended for use on D40x55 S3 – D100x140 S3 Navigator® horizontal directional drills
• Firestick® drill rod thread 2.875” #750 – 3.5” #1000; 2.375” – 4.5” API
• Rock drill heads, air hammers and mud motors

Components

Wrenches

• Operationally and cosmetically similar to the popular PBD11500 set
• Forged alloy for strength and durability
• 45 lb (20.4 kg) per wrench for ease of handling
• Two sets of dies to select high or low grip range positions

Cylinder

• OEM-specified hydraulic cylinder included
• 40 lb (18.1 kg)

Power unit

• OEM-specified, portable 28V hydraulic power unit
• Powered by a Milwaukee lithium battery
• Two batteries included
• Batteries charge in approximately 1 hour
• Two 20’ (6.1 m) hoses for ease of operation outside of the exit pit
• Components are precharged with oil for out-of-the-box readiness
• 26 lb (11.8 kg)

Tools and Accessories

• Allen wrench included for die changeout
• Hard plastic storage case included for hydraulic power unit, dies, batteries and wrenches
• Wood crate included for hydraulic unit case, wrenches, cylinder and hoses
• Tricone and PDC bit breaker accessories available
