8-in (20-cm) Replaceable Wing PDC Hole Opener
- SKU:
- 296501339
- UPC:
- Weight:
- 104.00 LBS
- Shipping:
- Calculated at Checkout
View Product Specifications
Hide Product Specifications
-
Model Compatibility
- D23x30 S3
- D23x30DR S3
- D24x40 Series II
- D24x40 S3
- D36x50 Series II
- D36x50DR Series II
- D40x55 S3
- D40x55DR S3
- D50x100 Series II
- D60x90
- D60x90 S3
- D80x100
- D80x100 Series II
- D100x120
- D100x120 Series II
- Front Connection 3.5-in (8.9-cm) API Reg Pin
-
Ground Conditions
- Cobble
- Fractured Rock
- Soft Rock
- Hard Rock
- Cutting Size 8 in (20.3 cm)
- Adapter Required? Yes
Videos Hide Videos Show Videos
Product Description
✔ The Vermeer-designed and manufactured line of PDC (polycrystalline diamond compact) hole openers bring performance and reliability to consolidated rock bores.
✔ From a standard 2.875-in (2 7/8”) API box x box body, contractors can interchange wing sets for cutting diameters of 8 in (20 cm), 10 in (25 cm) and 12 in (30 cm). With the ability to change sizes, users can maximize their investment in the single body. And in the event of wing damage, a single replacement wing can be purchased and installed in the field, rather than taking the tool out of service for an extended repair period.
✔Vermeer has sourced premium PDC inserts. In an independent test, these inserts showed better wear characteristics than the inserts commonly found in PDC pilot bits.
✔Carbide buttons span the profile of the cutter to assist stabilization and extend wear life.
✔ The hardfaced shaft helps reduce hourglass-style wear common in rock applications.
✔ Designed with 25 threaded fluid nozzles with 10 optional plugs for customizable drilling fluid management.
✔ Welded on rotary backout cutters.
✔ Industry research-informed PDC insert pitch for optimized balance rate of penetration and impact resistance.
